Baxtran - MBX 4 Load Cell Platform Scale - Enamelled Steel

Baxtran MBX 4 Load Cell Platform Scale

By Baxtran

The Baxtran MBX 4 Load Cell Platform Scale. Equipped with four high-accuracy load cells, this scale offers exceptional precision and stability. Its diamond plate platform ensures durability and resistance to wear and tear, while the sturdy steel framework provides a solid foundation for accurate weighing.

Product Information

Features:

  • Precision Weighing: Four load cells provide highly accurate weight measurement, ensuring reliable results for critical applications.
  • Legal Metrology Compliance: Adheres to strict legal metrology standards, making it suitable for industries requiring traceable and verifiable weighing data.
  • Ground-Level Installation: Easily integrates into existing facilities, saving space and simplifying installation.
  • Robust Construction: The diamond plate top and steel frame offer exceptional durability, withstanding heavy loads and harsh environments.
  • IP-Rated Protection: OIML R-60 C3 load cells and an IP66 junction box provide protection against moisture, dust, and other contaminants, ensuring long-term performance.
  • Adjustable Feet: Allows for easy leveling on uneven surfaces, ensuring accurate measurements.
  • Flexible Installation: The 5-meter cable offers flexibility in positioning the scale, accommodating various layout requirements.
Specification

Platform Dimensions:

  • 1200mm x 1200mm
  • 1500mm x 1200mm
  • 1500mm x 1500mm
  • 2000mm x 1500mm

Construction: Black Enamelled Steel

Load Cell Type: Load cells in steel, IP67 protection.

Load Cell Rating: OIML R-60 C3

Protection Rating: IP66 ABS Junction Box

Cable Length: 5 metres

Platform Thickness: 6 mm
Downloads

Please click here for the Baxtran MBX 4 Load Cell Platform Scale Datasheet.
